Example 3: Heat equation

In this example, we show how to minimize the shape function

\[J(\Omega) = \int_\Omega (u(T, \mathbf{x}) - u_t(\mathbf{x}))^2 \,\mathrm{d}\mathbf{x}\,,\]

where \(u_t:\mathbb{R}^3\to\mathbb{R}\) is a target temperature profile and \(u:[0,T]\times\mathbb{R}^3\to\mathbb{R}\) is the solution to the heat equation

\[\begin{split}\partial_t u - \Delta u = f\quad \text{in }(0,T]\times\Omega\,,\\ u(0,\cdot)=u_0 \quad \text{in }\Omega\,,\\ u(\cdot,\mathbf{x})=0\quad \text{on }\partial\Omega\,.\end{split}\]

In particular, we consider \(T=\pi/2\),

\[u_t(x,y,z) = 0.64 - (x - 0.5)^2 - (y - 0.5)^2 - (z - 0.5)^2\,,\]

and

\[f(t,x,y,z) = 6\sin(t) + \cos(t)\, u_t(x, y, z)\,.\]

The domain that minimizes \(J(\Omega)\) is a ball of radius \(0.8\) centered at \((0.5,0.5,0.5)\).

In the following, we describe how to solve this problem in Fireshape. The entire script is contained in the Python file heat.py, which is saved in the Fireshape repository and can be found at the following link: link-to-heat-example.

Import modules

We begin by importing Firedrake, Fireshape, and ROL.

from firedrake import *
from fireshape import *
import ROL

Implement the shape function

To implement the shape function \(J\), we use Fireshape’s class PDEconstrainedObjective. This requires specifying how to evaluate \(J\) in the method PDEconstrainedObjective.objective_value. To solve the heat equation, we use the implicit Euler method with 10 time steps.

class TargetHeat(PDEconstrainedObjective):
    """L2 misfit function constrained to the heat equation."""
    def __init__(self, *args, **kwargs):
        super().__init__(*args, **kwargs)
        self.mesh = self.Q.mesh_m

        # Setup problem
        V = FunctionSpace(self.mesh_m, "CG", 1)
        self.u = Function(V, name="Temperature")
        self.u_ = Function(V)
        self.u0 = Function(V)  # initial condition

        # Time discretization parameters
        self.N = 10  # number of time steps
        self.dt = (pi / 2) / self.N  # time step length

        # target temperature profile, exact solution is a ball of radius 0.8
        # centered at (0.5,0.5,0.5)
        (x, y, z) = SpatialCoordinate(self.mesh_m)
        self.u_t = 0.64 - (x - 0.5)**2 - (y - 0.5)**2 - (z - 0.5)**2

        # Weak form of implicit Euler applied to Heat equation
        u = self.u
        u_ = self.u_
        v = TestFunction(V)
        self.a = Constant(6 * sin(self.dt))
        self.b = Constant(cos(self.dt))
        f = self.a + self.b * self.u_t  # manufactured source term
        F = ((u - u_) * v / self.dt + inner(grad(u), grad(v)) - f * v) * dx
        bcs = DirichletBC(V, 0., "on_boundary")
        stateproblem = NonlinearVariationalProblem(F, self.u, bcs=bcs)
        self.solver = NonlinearVariationalSolver(stateproblem)

    def compute_temperature(self, name=None):
        """
        Solve heat equation. If input name is passed, store
        temperature time evolution in corresponding file.
        """
        # assign initial condition
        self.u_.assign(self.u0)
        self.u.assign(self.u0)

        if name is not None:
            print("Storing the " + name + " temperature evolution.")
            out = VTKFile(name + "_temperature_evolution.pvd")
            out.write(self.u, time=0)

        for ii in range(self.N):
            # update source term coefficients
            t = (ii + 1) * self.dt
            self.a.assign(6 * sin(t))
            self.b.assign(cos(t))
            # perform time step
            self.solver.solve()
            self.u_.assign(self.u)
            if name is not None:
                out.write(self.u, time=t)

    def objective_value(self):
        self.compute_temperature()
        return assemble((self.u - self.u_t)**2 * dx)

Select initial guess, control space, and inner product

We select a unit disk centered at the origin as initial domain. To modify the domain, we create a control space of geometric transformations discretized using finite elements. To compute descent directions, we employ Riesz representatives of shape derivatives with respect to a full \(H^1\)-inner product. With these, we create a control variable q that will be updated by the optimization algorithm.

# Select initial guess, control space, and inner product
mesh = UnitBallMesh(refinement_level=3)
Q = FeControlSpace(mesh)
IP = H1InnerProduct(Q)
q = ControlVector(Q, IP)

Instantiate objective function J

We instantiate \(J(\Omega)\) using the class TargetHeat we have created. During instantiation, we also pass a call back function cb that stores the shape iterates whenever J is evaluated. We also store the evolution of the temperature profile on the initial domain.

# Instantiate objective function J
out = VTKFile("domain.pvd")
J = TargetHeat(Q, cb=lambda: out.write(Q.mesh_m.coordinates))
J.compute_temperature("initial")

Select the optimization algorithm and solve the problem

Finally, we select a trust-region optimization algorithm with l-BFGS Hessian updates and set the optimization stopping criteria in the dictionary pd. This, together with J and q are passed to ROL, which solves the problem. When the optimization algorithms has stopped, we store the evolution of the temperature profile on the optimized domain.

# Select the optimization algorithm and solve the problem
pd = {'Step': {'Type': 'Trust Region'},
      'General': {'Secant': {'Type': 'Limited-Memory BFGS',
                                     'Maximum Storage': 25}},
      'Status Test': {'Gradient Tolerance': 1e-3,
                      'Step Tolerance': 1e-8,
                      'Iteration Limit': 30}}
params = ROL.ParameterList(pd, "Parameters")
problem = ROL.OptimizationProblem(J, q)
solver = ROL.OptimizationSolver(problem, params)
solver.solve()
J.compute_temperature("final")

Result

Typing python3 levelset.py in the terminal returns:

Storing the initial temperature evolution.

Dogleg Trust-Region Solver with Limited-Memory BFGS Hessian Approximation
  iter  value          gnorm          snorm          delta          #fval     #grad     tr_flag
  0     7.270316e+00   1.687694e+01                  1.687694e+01
  1     7.270316e+00   1.687694e+01   1.687694e+01   3.068535e+00   3         1         5
  2     7.270316e+00   1.687694e+01   3.068535e+00   3.341968e-01   4         1         5
  3     3.166234e+00   8.472555e+00   3.341968e-01   3.341968e-01   5         2         0
  4     1.193140e+00   3.822150e+00   3.341968e-01   8.354921e-01   6         3         0
  5     4.522666e-01   1.745016e+00   2.762971e-01   2.088730e+00   7         4         0
  6     1.692963e-01   7.689023e-01   2.341998e-01   5.221825e+00   8         5         0
  7     7.025110e-02   3.313803e-01   1.875483e-01   1.305456e+01   9         6         0
  8     3.602387e-02   1.456138e-01   1.508964e-01   3.263641e+01   10        7         0
  9     1.990907e-02   9.035061e-02   1.493638e-01   8.159102e+01   11        8         0
  10    4.282918e-03   4.940063e-02   2.828876e-01   2.039776e+02   12        9         0
  11    2.436980e-03   3.761708e-02   7.220499e-02   5.099439e+02   13        10        0
  12    1.130037e-04   6.559129e-03   1.380168e-01   1.274860e+03   14        11        0
  13    7.578703e-05   3.833176e-03   1.429239e-02   1.274860e+03   15        12        0
  14    6.393627e-05   2.059663e-03   4.817841e-03   3.187149e+03   16        13        0
  15    5.661970e-05   1.580813e-03   6.664030e-03   7.967873e+03   17        14        0
  16    5.173678e-05   1.058514e-03   6.662573e-03   1.991968e+04   18        15        0
  17    4.982127e-05   3.074662e-04   4.933308e-03   4.979921e+04   19        16        0
Optimization Terminated with Status: Converged
Storing the final temperature evolution.

We can inspect the result by opening the file levelset_domain.pvd with ParaView. In the GIF below, we see that temperature evolution in the initial domain, the domain (black grid) converging to the right shape (red ball), and the temperature evolution in the optimized domain.
